Suitable for most engines. Charge and battery condition. Voltage independent – suitable for 12 & 24V Ammeters with internal shunt are easily identified by the heavy duty threaded terminals. Heavy duty wire must be used for wiring. Illumination globe holder included.
For 24V application use globe 999-065-002 For 12V application use globe 999-065-001

Suitable for most engines. Charge and battery condition. Voltage independent – suitable for 12 & 24V Ammeters with internal shunt are easily identified by the heavy duty threaded terminals. Heavy duty wire must be used for wiring. Illumination globe holder included.
For 24V application use globe 999-065-002 For 12V application use globe 999-065-001

The VDO Quartz Clock offers accurate timing to within ±1 second per day. The crystallographic properties of quartz ensure that the electric current is precisely regulated for accurate timing.

Suitable for use with petrol and diesel fuel.
Illumination 12V and 24V included.
FUEL GAUGES 10-180 ohms, For tank units with 10-180 ohms resistance. Without ISO symbol.

With ISO symbol for fuel level
For tubular tank units, adjustable resistance range
Full 3 ohm | Empty 9 ohm
TUBULAR TYPE SENDERS (PCD* Pitch Circle Diameter)

Suitable for all vehicles and machines
Available with 360° - minute hand sweep or as counters only

Suitable for all vehicles and machines
Available with 360° - minute hand sweep or as counters only

Suitable for all vehicles and machines.
Illumination 12V or 24V included. Note: Not recommended for petrol or water.
PRESSURE GAUGES, Engine Oil Pressure 500kPa

Suitable for all vehicles and machines.
Illumination 12V or 24V included. Note: Not recommended for petrol or water.
PRESSURE GAUGES, Engine Oil Pressure 500kPa

Suitable for all vehicles and machines.
Illumination 12V or 24V included. Note: Not recommended for petrol or water.
PRESSURE GAUGES, Engine Oil Pressure 500kPa

Suitable for most vehicles and machines. Can be used on most
non-aggressive gases and liquids. Supplied with nut and cone
for 3/6” PVC tubing. Globe Holder not included.
For 24V application use globe part no. 999-065-002
For 12V application use globe part no. 999-065-001

Suitable for all vehicles.
Supplied with nut and cone for 3/16” PVC tubing.
Illumination 12V included

Suitable for all vehicles.
Illumination 12V included

Suitable for all engines and machines.
Monitors charge and battery condition.
Illumination 12V or 24V included

Diameter : 100 mm
Colour : Black
Lens: clear
Power supply : 12 V
Proven backlight technology, good visible by day and by night
Sensor not included, it is not necessary

Floodlit illumination. 12V globe included. Field adjustable to suit 500 to 400,000 imp/km by pulse setting or auto- calibration function through LCD readout via reset button. Total Distance 999,999.9 not resettable. Speed display analogue; Odometer And trip distance LC-display trip distance 99,999.9 resettable. Signal source Hall Effect, inductive or blocking oscillator
Sender units. For 24V application use globe 999-065-002 (2 required).
Note: 140mm speedometer impulse Radio programmable 1000-60000 pulses/Km (via software).

Colour: Black
Panel hole diameter: 80 mm - 3 1/8"
Range: 0 to 120 Km/h
Operating voltage: 12-24 Volt DC

VDO Tachometer 6000 RPM

Colour: Black
Panel hole diameter: 80 mm - 3 1/8"
Range: 0 to 6000 RPM
Operating voltage: 12-24 Volt DC

VDO Cockpit International Tachometer 6000 RPM 80mm 12-24V

Colour: Black
Panel hole diameter: 80 mm - 3 1/8"
Range: 0 to 6.000 RPM
Operating voltage: 12-24 Volt DC

VDO Cockpit International Tachometer 3000 RPM 100mm 12-24V

Colour: Black
Panel hole diameter: 100 mm - 4"
Range: 0 to 3.000 RPM
Operating voltage: 12-24 Volt DC

VDO Cockpit International Tachometer 3000 RPM 80mm 12V

Colour: Black
Panel hole diameter: 80 mm - 3 1/8"
Range: 0 to 3.000 RPM
Operating voltage: 12 Volt DC

VDO Cockpit International Tachometer 4.000 RPM 80mm 12V

Colour: Black
Panel hole diameter: 80 mm - 3 1/8"
Range: 0 to 4.000 RPM
Operating voltage: 12 Volt DC

VDO Cockpit International Tachometer 7000 RPM 80mm 12V

Colour: Black
Panel hole diameter: 80 mm - 3 1/8"
Range: 0 to 7.000 RPM
Operating voltage: 12 Volt DC

VDO Cockpit International Tachometer 8000 RPM 80mm 12V

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: 0 to 8000 RPM
Operating voltage: 12 Volt DC
Retail package 1 Tachometer

VDO Oil temperature Gauge 120°C 52mm 24V

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: +40°C to +120°C
Operating voltage: 24 Volt DC

VDO Coolant temperature Gauge 120°C

VDO Cockpit International Gear oil temperature 150°C 52mm 24V

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: +50°C to +150°C
Operating voltage: 24 Volt DC
OEM Temperature gauges

VDO Engine oil temperature Gauge 150°C 52mm 12V

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: +50°C to +150°C
Operating voltage: 12 Volt DC
OEM Temperature gauges

VDO Cockpit International Oil temperature 200°C 52mm 12V

Colour: Black Panel hole diameter: 52 mm - 2 1/16"
Range: +60°C to +200°C
Operating voltage: 12 Volt DC
OEM Temperature gauges

VDO Coolant temperature mechanical 120°C

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: +40°C to +120°C Mechanical
Connection: M10 x 1

VDO Cockpit International Oil temperature Gauge mechanical 150°C 52mm

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: +40°C to +150°C Mechanical
Connection: M10 x 1
Retail package 1 Temperature gauge

VDO Temperature Gauge 900°C (52mm)

Colour: Black
Panel hole diameter: 52 mm - 2 1/16"
Range: +100°C to +900°C
Operating voltage: 12 Volt DC
